Ubiquiti EdgeSwitch ES-24-250W Gigabit PoE+ Managed Switch 24x1G RJ45, 2x SFP, 250W

Ubiquiti EdgeSwitch ES-24-250W Managed PoE Switch

The Ubiquiti EdgeSwitch ES-24-250W is a professional-grade managed network switch designed for robust enterprise and SMB networking. It features 24 Gigabit RJ45 ports with flexible PoE capabilities and 2 high-speed SFP ports, all housed in a compact 1U rackmount form factor, enabling reliable and scalable network deployments.

Key benefits

• Flexible PoE support: Supports both active 802.3af/at and passive 24V PoE configurations per port.
• High throughput: Total switching capacity of 26 Gbps ensures smooth data flow in demanding environments.
• Versatile connectivity: Includes 2 hot-swappable SFP ports for fiber uplinks or extended reach.
• Centralized management: Integrates with UniFi OS Console, supports SNMP, SSH, CLI, and IPv6 management for comprehensive control.
• Reliable operation: Built-in ESD/EMP protection and four fans for stable performance under load.

Technical Specifications

• Ports: 24 × 10/100/1000 BaseT RJ-45 with STP, 2 × SFP hot-swappable
• PoE power: Up to 250W total, 34.2W max per port via 802.3af/at or 17W via passive 24V options
• Switching throughput: 26 Gbps aggregate bandwidth
• Power supply: 100-240V AC, 50-60Hz input
• Management: UniFi OS Console support, CLI, SNMP v1/v2/v3, SSH, SSL/TLS, SCP, Telnet
• Cooling: Four integrated fans for active thermal management
• Protection: ESD/EMP air and contact protection at ±24 kV
• Dimensions: 485 × 44.45 × 285.6 mm (WxHxD), Rackmount 1U
• Weight: 3.7 kg

Ideal for

• Enterprise and SMB networks requiring centralized PoE device support
• Data centers or wiring closets needing rackmount Gigabit switches
• Network environments demanding robust security and management features

Package contents

• Ubiquiti EdgeSwitch ES-24-250W unit
• Power cable
• Rackmount mounting kit
• User manual and documentation
